SYNOPSYS™15.65 版本发布

The update to version 15.65 incorporates the following changes:

Features:

1.AED now honors switch 99.

2.AED now honors switch 99.

3.The behavior of object type OBD has been revised.Before,the size of the entering beam would change if the first radius of curvature changed -- which made no sense. Now the default pupil with this object type traces a beam with constant size measured perpendicular to the chief ray. This is similar to the effect of the WAP 1 pupil,although the position of the rim rays still varies somewhat if the first radius is steep. Once you change to a real pupil and implement WAP 2 or 3,this size is adjusted,as before.

Bugs Fixed:

1.The TN function crashed in the previous version.

2.The lens layout tool (LLT) crashed if a previous optimization used the SNAP option.

3.Problems were discovered that involved certain combinations of ZSEARCH, OBD, VFIELD, ACONS, PAD SCAN,and optimization with switch 99 turned on.

4.The quick mode in ZSEARCH did not honor all of the SPECIAL AANT entries correctly.

5.The automatic aspheric assignment AAA did not return the best case if any of them encountered ray failures.

6.REVERSE did not work properly on zoom lenses.
